GLDA-Na4 in Automatic Dishwashing: Filming and Scale Control

Phosphates did three jobs in automatic dishwashing at once: soften the water, disperse the soil and buffer the alkalinity. When EU rules restricted phosphorus in consumer automatic dishwasher detergents from the start of 2017, formulators had to rebuild that functionality from parts. Tetrasodium glutamate diacetate — GLDA-Na4, CAS 51981-21-6 — is one of the biodegradable chelators now carrying the water-softening share of that load. It holds its chelation across the alkaline pH of a main wash and degrades well above 60% within 28 days under OECD 301 testing.

This article covers how GLDA-Na4 behaves through the dishwasher cycle, what it does for filming, spotting and machine scale, and the compatibility points formulators should check before committing to it.

What the phosphate restriction actually removed

Regulation (EC) No 648/2004, as amended by Regulation (EU) No 259/2012, limits phosphorus in consumer automatic dishwasher detergents to 0.3 g per standard dosage. Consumer laundry detergents had already been limited, from mid-2013.

Removing phosphate took away more than sequestration. Sodium tripolyphosphate also dispersed soil particles, kept them from redepositing, and contributed to the alkaline buffer that saponifies fatty soils. A chelator only replaces the first of those. The rest has to come from elsewhere in the formulation, which is why workable phosphate-free systems tend to be blends rather than single-ingredient swaps.

The ingredients carrying that load today fall into three groups:

• Chelators: GLDA-Na4, MGDA-Na3, IDS-Na4, EDDS, citrates.

• Dispersants: polycarboxylates and sulphonated polymers.

• Builders and buffers: silicates, carbonates, and in powders, zeolites.

What GLDA-Na4 does through the wash cycle

An automatic dishwashing main wash runs hot and alkaline — commonly 50–65 °C at a pH around 10–11, followed by rinse and drying phases. GLDA-Na4 holds its chelation across that range and stays soluble, which is the baseline requirement for anything used in the cycle.

Filming and spotting

Filming is the thin inorganic deposit that dulls glassware; spotting is the residue left behind when a drying droplet evaporates. Both trace back to hardness ions, and both are the first things a consumer notices.

GLDA-Na4 keeps calcium and magnesium in solution through the main wash, so less material is available to deposit as the cycle cools and the water evaporates. Its dry-basis sequestration is around 45 mg/g for calcium and 27 mg/g for magnesium, with considerably higher figures for iron, copper and manganese.

In a working formulation the chelator and the polymer dispersant do different halves of the job: the chelator complexes the ion, and the dispersant keeps the resulting particle suspended so it leaves with the drain water.

Bleachable soils

Tea, coffee and some fruit soils are bleachable — they need an oxidising agent, and that oxidising agent needs protection from the transition metals that would otherwise decompose it before it reaches the stain. GLDA-Na4's strong copper and iron binding, roughly 72 and 63 mg/g on a dry basis, does that protective work, which is why it pairs well with percarbonate and TAED systems.

Machine and heater protection

Limescale on heating elements and spray arms shortens machine life and lengthens cycle times. Keeping hardness ions complexed through the cycle reduces deposition on those surfaces. That is one reason GLDA-Na4 also appears in dedicated machine-cleaning and descaling products, not only in detergents.

Formats: tablet, powder, gel and liquid

Physical format drives the choice more than chemistry does for most manufacturers.

Format	Consideration for GLDA-Na4
Tablet / powder	The 47% liquid grade is carried on a solid base or granulated; suits plants already handling liquids in production
Gel	Good fit — the chelator disperses readily through the gel matrix
Liquid / unit-dose	Strong fit — full miscibility and stability at high active matter
Rinse aid	Used less often; the main wash usually carries the chelator load

For tablets specifically, the trade-off will be familiar. A liquid chelator has to be absorbed onto a carrier, which dilutes the product slightly and adds a processing step. Manufacturers already set up for spray-dried or granulated grades may find solid chelators more convenient; where the plant handles liquids, GLDA-Na4 avoids that step entirely.

Beyond the dishwasher: hard surface cleaners

The same mechanism carries into household hard-surface products:

• Kitchen and bathroom sprays, where limescale is the visible soil and the chelator works alongside acid or at moderate alkalinity.

• Glass and window cleaners, where mineral residue causes streaking.

• Limescale removers, where GLDA-Na4 works down to around pH 2 as comfortably as at pH 11.

• Machine descalers for kettles, coffee machines and dishwashers, where it dissolves carbonate deposits without the handling problems of strong mineral acids.

Compatibility checks before reformulating

Three areas deserve attention.

• Enzymes. Proteases and amylases in dishwasher tablets can depend on bound calcium. Confirm stability with the enzyme supplier, particularly for amylase-containing systems.

• Glass and decoration. Any strong chelator in a high-pH cycle can affect glass, glaze and applied decoration over many cycles. Material compatibility needs testing in the finished formulation rather than being assumed from the ingredient data.

• Bleach. GLDA-Na4 generally supports percarbonate systems by removing catalytic metals, but as with any formulation change, confirm performance in the full system rather than in isolation.

Dosing

Application	GLDA-Na4 (as supplied) in formulation
Automatic dishwashing tablet / powder	2–6%
Automatic dishwashing gel	3–8%
Rinse aid (where used)	0.5–2%
Household limescale remover	3–10%
Machine descaler	5–15%

These are working ranges for a 47% active grade. The right dose depends on the hardness of the target market's water and on what else in the formulation is contributing sequestration and dispersion.

Frequently asked questions

Is GLDA-Na4 accepted under EU Ecolabel for dishwashing products?

It meets the biodegradability criteria used by EU Ecolabel and Nordic Swan. As criteria are revised periodically, check the current version for the specific product category before making a certified claim.

Does it replace the polymer dispersant as well?

No. The chelator handles hardness ions; the dispersant keeps particles suspended. Phosphate-free systems generally need both.

How does it compare with MGDA-Na3 in dishwashing?

MGDA-Na3 has a long track record in phosphate-free automatic dishwashing and is available in solid grades, which suits tablets. GLDA-Na4 offers high solubility and straightforward liquid handling. Many manufacturers trial both against their own soil and water conditions.

Can it be used in rinse aids?

It can, at low levels, though most formulations put the chelator load in the main wash.

Conclusion

GLDA-Na4 addresses the part of the phosphate legacy that a chelator can address: keeping hardness ions in solution across a hot, alkaline cycle, so that glassware comes out clear and machine surfaces stay free of scale. Its transition-metal binding adds a second benefit in removing bleachable soils.

What it does not do is replace the dispersant or the buffer. Phosphate-free dishwashing is a system problem, and the formulations that perform well tend to be built as blends and then validated against real water hardness — a trial on the actual soil and water settles the question faster than any comparison table.
